of 676 results found
View:

Filters

KZZVV-65D-R5 KZZVV-65D-R5
10-port sector antenna, 2x 617–960, 4x 1427–2690 MHz and 4x 1695–2690 MHz, 65° HPBW, 5x RET with tilt indicators
KZZVV-65D-R5
  • Product type: Sector antenna
  • Operating frequency band range: 1427 – 2700 MHz | 575 – 960 MHz
  • Horizontal beamwidth: 65°
  • Length size: 3.0 m (10 ft)+
  • Width/diameter: 306 – 353 mm
  • Rf connector interface: 4.3-10 Female
  • Rf connector quantity, total: 10
  • Rf connector quantity, high band: 8
  • Rf connector quantity, mid band: 0
  • Rf connector quantity, low band: 2
SpecificationsSpecs
KZZVV-65D-R5
  • Product type: Sector antenna
  • Operating frequency band range: 1427 – 2700 MHz | 575 – 960 MHz
  • Horizontal beamwidth: 65°
  • Length size: 3.0 m (10 ft)+
  • Width/diameter: 306 – 353 mm
  • Rf connector interface: 4.3-10 Female
  • Rf connector quantity, total: 10
  • Rf connector quantity, high band: 8
  • Rf connector quantity, mid band: 0
  • Rf connector quantity, low band: 2
LDX-3319DS-VTM | LDX-3319DS-A1M LDX-3319DS-VTM | LDX-3319DS-A1M
2-port sector antenna, 2x 790–960 MHz, 33° HPBW, RET compatible
LDX-3319DS-VTM | LDX-3319DS-A1M
  • Product type: Sector antenna
  • Operating frequency band range: 575 – 960 MHz
  • Horizontal beamwidth: 33°
  • Length size: 2.5 m (8 ft)
  • Width/diameter: > 499 mm
  • Rf connector interface: 7-16 DIN Female
  • Rf connector quantity, total: 2
  • Rf connector quantity, high band: 0
  • Rf connector quantity, mid band: 0
  • Rf connector quantity, low band: 2
SpecificationsSpecs
LDX-3319DS-VTM | LDX-3319DS-A1M
  • Product type: Sector antenna
  • Operating frequency band range: 575 – 960 MHz
  • Horizontal beamwidth: 33°
  • Length size: 2.5 m (8 ft)
  • Width/diameter: > 499 mm
  • Rf connector interface: 7-16 DIN Female
  • Rf connector quantity, total: 2
  • Rf connector quantity, high band: 0
  • Rf connector quantity, mid band: 0
  • Rf connector quantity, low band: 2
LLPX210R-V1 LLPX210R-V1
4-port sector antenna, 4x 2300–2700 MHz, 33° HPBW, 2x RET with manual override
LLPX210R-V1
  • Product type: Sector antenna
  • Operating frequency band range: 1427 – 2700 MHz
  • Horizontal beamwidth: 33°
  • Length size: 0.7 m (2 ft)
  • Width/diameter: > 499 mm
  • Rf connector interface: 7-16 DIN Female
  • Rf connector quantity, total: 4
  • Rf connector quantity, high band: 4
  • Rf connector quantity, mid band: 0
  • Rf connector quantity, low band: 0
SpecificationsSpecs
LLPX210R-V1
  • Product type: Sector antenna
  • Operating frequency band range: 1427 – 2700 MHz
  • Horizontal beamwidth: 33°
  • Length size: 0.7 m (2 ft)
  • Width/diameter: > 499 mm
  • Rf connector interface: 7-16 DIN Female
  • Rf connector quantity, total: 4
  • Rf connector quantity, high band: 4
  • Rf connector quantity, mid band: 0
  • Rf connector quantity, low band: 0
LLPX310R-V1 LLPX310R-V1
4-port sector antenna, 4x 2300–2700 MHz, 65° HPBW, 2x RET with manual override
LLPX310R-V1
  • Product type: Sector antenna
  • Operating frequency band range: 1427 – 2700 MHz
  • Horizontal beamwidth: 65°
  • Length size: 0.7 m (2 ft)
  • Width/diameter: 201 – 305 mm
  • Rf connector interface: 7-16 DIN Female
  • Rf connector quantity, total: 4
  • Rf connector quantity, high band: 4
  • Rf connector quantity, mid band: 0
  • Rf connector quantity, low band: 0
SpecificationsSpecs
LLPX310R-V1
  • Product type: Sector antenna
  • Operating frequency band range: 1427 – 2700 MHz
  • Horizontal beamwidth: 65°
  • Length size: 0.7 m (2 ft)
  • Width/diameter: 201 – 305 mm
  • Rf connector interface: 7-16 DIN Female
  • Rf connector quantity, total: 4
  • Rf connector quantity, high band: 4
  • Rf connector quantity, mid band: 0
  • Rf connector quantity, low band: 0
LNX003U-V2 LNX003U-V2
H\V Pol Omni Antenna, 2490–2690 MHz, 360° horizontal beamwidth
LNX003U-V2
  • Product type: Omnidirectional antenna
  • Operating frequency band range: 1427 – 2700 MHz
  • Horizontal beamwidth: 360°
  • Length size: 0.7 m (2 ft)
  • Width/diameter: ≤ 200 mm
  • Rf connector interface: 4.3-10 Female
  • Rf connector quantity, total: 2
  • Rf connector quantity, high band: 2
  • Rf connector quantity, mid band: 0
  • Rf connector quantity, low band: 0
SpecificationsSpecs
LNX003U-V2
  • Product type: Omnidirectional antenna
  • Operating frequency band range: 1427 – 2700 MHz
  • Horizontal beamwidth: 360°
  • Length size: 0.7 m (2 ft)
  • Width/diameter: ≤ 200 mm
  • Rf connector interface: 4.3-10 Female
  • Rf connector quantity, total: 2
  • Rf connector quantity, high band: 2
  • Rf connector quantity, mid band: 0
  • Rf connector quantity, low band: 0
MB12P4L8M6533B6-V2 MB12P4L8M6533B6-V2
12-port sector/multibeam antenna, 4x 698–960 MHz 65° HPBW and 8x 1710–2690 MHz 33°HPBW, 6x RET
MB12P4L8M6533B6-V2
  • Product type: Multibeam antenna
  • Operating frequency band range: 1427 – 2700 MHz | 575 – 960 MHz
  • Horizontal beamwidth: 33° | 65°
  • Length size: 2.0 m (6 ft)
  • Width/diameter: > 499 mm
  • Rf connector interface: 7-16 DIN Female
  • Rf connector quantity, total: 12
  • Rf connector quantity, mid band: 8
  • Rf connector quantity, low band: 4
SpecificationsSpecs
MB12P4L8M6533B6-V2
  • Product type: Multibeam antenna
  • Operating frequency band range: 1427 – 2700 MHz | 575 – 960 MHz
  • Horizontal beamwidth: 33° | 65°
  • Length size: 2.0 m (6 ft)
  • Width/diameter: > 499 mm
  • Rf connector interface: 7-16 DIN Female
  • Rf connector quantity, total: 12
  • Rf connector quantity, mid band: 8
  • Rf connector quantity, low band: 4
MC-MNT-3XV-SIDE MC-MNT-3XV-SIDE
Small Cell mounting kit with shroud. Capability of mounting round antenna types on the side of a pole or building.
MC-MNT-3XV-SIDE
  • Product type: Side mounting kit
SpecificationsSpecs
MC-MNT-3XV-SIDE
  • Product type: Side mounting kit
MC-MNT-3XV-TOP MC-MNT-3XV-TOP
Small Cell mounting kit with shroud. Capability of mounting round antenna types on the top of a pole. For installations of 7.9 inch canister small cell antennas on top of poles with a diameter from 61 to 91 mm (2.4" to 3.6")
MC-MNT-3XV-TOP
  • Product type: Pole mount kit
SpecificationsSpecs
MC-MNT-3XV-TOP
  • Product type: Pole mount kit
MC-MNT-3XV-TS1 MC-MNT-3XV-TS1
Small Cell mounting kit . Capability of mounting round antenna types on the top or side of a pole or on the side of a building.
MC-MNT-3XV-TS1
  • Product type: Side mounting kit
SpecificationsSpecs
MC-MNT-3XV-TS1
  • Product type: Side mounting kit
MC-MNT-SIDE-370 MC-MNT-SIDE-370
Mounting systems for cylindrical pipe installations (50-250mm pipe diameter) .Suitable for small cell cylindrical antennas with a weight less than 20KG and dimensions less than diameter*height: 370*610mm.
MC-MNT-SIDE-370
  • Product type: Side mounting kit
SpecificationsSpecs
MC-MNT-SIDE-370
  • Product type: Side mounting kit
MC-MNT-TOP MC-MNT-TOP
Small Cell mounting kit with shroud. Capability of mounting round antenna types on top of a pole. For installations of 12 inch canister small cell antennas on top of poles with diameter from 86 to 168 mm (3.4” to 6.6”)
MC-MNT-TOP
  • Product type: Pole mount kit
SpecificationsSpecs
MC-MNT-TOP
  • Product type: Pole mount kit
MC-MNT-TOP-2 MC-MNT-TOP-2
Small Cell mounting kit with shroud. Capability of mounting round antenna types on the top of a pole. For installations of 12 inch canister small cell antennas on top of poles with diameter from 160 to 216mm (6.3” to 8.5”)
MC-MNT-TOP-2
  • Product type: Pole mount kit
SpecificationsSpecs
MC-MNT-TOP-2
  • Product type: Pole mount kit
